| Model |
AC1500
|
AC2000
|
BC2000
|
BC3000
|
BC4000
|
| Fluid |
Air
|
| Port size |
G1/8″
|
G1/4″
|
G1/4″
|
G3/8″
|
G1/2″
|
| Filtering grade |
40μ
|
| Pressure range |
0.05 ~ 0.85MPa
|
| Max. pressure |
0.95MPa
|
| Proof pressure |
1.5MPa
|
| Operating temperature |
5 ~ 60oC
|
| Drain bowl capacity |
15 cc
|
60 cc
|
| Oil bowl capacity |
25 cc
|
90 cc
|
| Recommended lubricant |
ISO VG 32 or Equivalent
|
| Weight |
0.7 KG
|
0.9 KG
|
| Material |
Body |
Aluminum die-cast
|
| Bowl |
PC IR2200
|
| Bowl guard |
-
|
Nylon,Iron
|
| Component |
Filter |
AF1500
|
AF2000
|
BF2000
|
BF3000
|
BF4000
|
| Regulator |
AR1500
|
AR2000
|
BR2000
|
BR3000
|
BR4000
|
| Lubricator |
AL1500
|
AL2000
|
BL2000
|
BL3000
|
BL4000
|
|
|
