Model
|
Port size
|
Position and
way NO.
|
Port
siz
|
Fluid
|
Operating
pressure
range
|
Proof
pressure
|
Effective area
|
Answer time
|
Operating
temperature
|
Coil voltage
|
Power consumption
|
Allowable
voltage
|
Insulation
class
|
|
V-180-3E1,E2
|
6A
|
3/2 way
|
G1/8″ |
Air |
0.15~0.8MPa |
1.0MPa |
12mm2(CV=0.67) |
30ms |
5~50oC |
AC: 110V, 220V
(50/60)Hz
DC: 24V |
AC: 3.7/3.1VA
DC: 2.9W |
±10% |
Class F |
|
V-180-4E1,E2
|
5/2 way
|
12mm2(CV=0.67) |
|
V-180-4E2C.P.R
|
5/3 way
|
0.2~0.7MPa |
9mm2(CV=0.50) |
|
V-220-3E1,E2
|
8A
|
3/2 way
|
PT-1/4 |
Air |
0.2~0.7MPa |
1.0MPa |
18mm2(CV=1.00) |
30ms |
5~50oC |
AC: 110V, 220V
(50/60)Hz
DC: 24V |
AC: 6/4.9VA
DC: 2.5W |
±10% |
Class F |
|
V-220-4E1,E2
|
5/2 way
|
|
V-220-4E2C.P.R
|
5/3 way
|
0.3~0.7MPa |
16mm2(CV=0.89) |
|
V-260-4E1
|
8A
|
5/2 way
|
PT-1/4 |
Air |
0.2~0.7MPa |
1.0MPa |
18mm2(CV=1.00) |
40ms |
5~50oC |
AC: 110V, 220V
(50/60)Hz
DC: 24V |
AC: 6/4.9VA
DC: 2.5W |
±10% |
Class F |
|
V-260-4E2
|
|
V-260-4E2C.P.R
|
5/3 way
|
0.3~0.7MPa |
16mm2(CV=0.89) |
|
V-300-3E1,E2
|
10A
|
3/2 way
|
PT-3/8 |
Air |
0.2~0.7MPa |
1.0MPa |
35mm2(CV=1.96) |
40ms |
5~50oC |
AC: 110V, 220V
(50/60)Hz
DC: 24V |
AC: 6/4.9VA
DC: 2.5W |
±10% |
Class F |
|
V-300-4E1,E2
|
5/2 way
|
|
V-300-4E2C.P.R
|
5/3 way
|
0.3~0.7MPa |
25mm2(CV=1.40) |
|
V-460-3E1
|
15A
|
3/2 way
|
G-1/2 |
Air |
0.2~0.7MPa |
1.05MPa |
50mm2(CV=2.79) |
50ms |
5~50oC |
AC: 110V, 220V
(50/60)Hz
DC: 24V |
AC: 6/4.9VA
DC: 2.5W |
±10% |
Class F |
|
V-460-4E1,E2
|
5/2 way
|
|
V-460-4E2C.P.R
|
5/3 way
|
0.3~0.7MPa |
30mm2(CV=1.68) |
|
Blast-proof type
specifi cations
220260300460 Series solenoid
valve (sheet 1)
|
|
Blast-proof class
|
Ex m ¢òT4
|
|
Coil voltage
|
AC: 110V, 220V (50/60)Hz DC: 24V
|
|
Power consumption
|
AC: 4.4VA DC: 5W
|
|
Allowable voltage
|
±10% of rated voltage
|
|
Coil insulation
|
Class F
|
|
|
|
